How to Add, Extract, and Remove Images from Worksheets

Introduction

By adding images, users can enrich their data with relevant graphics or illustrations. Removing or deleting images simplifies content editing and organization. Additionally, the ability to retrieve images allows for repurposing them in other documents or applications, as well as updating existing images. Collectively, these features enhance user control over images, improve the overall user experience, and enable seamless image manipulation within Excel workbooks.


Get started with IronXL

Start using IronXL in your project today with a free trial.

First Step:
green arrow pointer


Add Images Example

To insert an image into a spreadsheet, utilize the InsertImage method, which supports various image types, such as JPG/JPEG, BMP, PNG, GIF, and TIFF. You must specify the top-left and bottom-right corners of the image to determine its dimensions, calculated by subtracting the column and row values. For example, you can try the following approaches:

  • For a 1x1 image size:
    • worksheet.InsertImage("image.gif", 5, 1, 6, 2);
  • For a 2x2 image size:
    • worksheet.InsertImage("image.gif", 5, 1, 7, 3);

Please note
The generated image IDs follow a pattern of 1, 3, 5, 7, and so on.

:path=/static-assets/excel/content-code-examples/how-to/add-remove-extract-worksheet-images-insert.cs
using IronXL;

WorkBook workBook = WorkBook.Create();
WorkSheet workSheet = workBook.DefaultWorkSheet;

// Insert images
workSheet.InsertImage("ironpdf.jpg", 2, 2, 4, 4);
workSheet.InsertImage("ironpdfIcon.png", 2, 6, 4, 8);

workBook.SaveAs("insertImages.xlsx");
Imports IronXL

Private workBook As WorkBook = WorkBook.Create()
Private workSheet As WorkSheet = workBook.DefaultWorkSheet

' Insert images
workSheet.InsertImage("ironpdf.jpg", 2, 2, 4, 4)
workSheet.InsertImage("ironpdfIcon.png", 2, 6, 4, 8)

workBook.SaveAs("insertImages.xlsx")
$vbLabelText   $csharpLabel

Output Spreadsheet

Insert Image

Extract Images Example

To extract images from the selected worksheet, simply access the Images property, which provides a list of all the images contained within the sheet. From this list, you can perform various operations such as exporting, resizing, retrieving positions, and obtaining the byte data of each image. Notably, the image IDs follow an odd-numbered pattern, incrementing in the sequence of 1, 3, 5, 7, and so on.

:path=/static-assets/excel/content-code-examples/how-to/add-remove-extract-worksheet-images-extract.cs
using IronSoftware.Drawing;
using IronXL;
using IronXL.Drawing;
using System;
using System.Collections.Generic;

WorkBook workBook = WorkBook.Load("insertImages.xlsx");
WorkSheet workSheet = workBook.DefaultWorkSheet;

// Retreive images
List<IronXL.Drawing.Images.IImage> images = workSheet.Images;

// Select each image
foreach (IronXL.Drawing.Images.IImage image in images)
{
    // Save the image
    AnyBitmap anyBitmap = image.ToAnyBitmap();
    anyBitmap.SaveAs($"{image.Id}.png");

    // Resize the image
    image.Resize(1,3);

    // Retrieve image position
    Position position = image.Position;
    Console.WriteLine("top row index: " + position.TopRowIndex);
    Console.WriteLine("bottom row index: " + position.BottomRowIndex);

    // Retrieve byte data
    byte[] imageByte = image.Data;
}

workBook.SaveAs("resizeImage.xlsx");
Imports IronSoftware.Drawing
Imports IronXL
Imports IronXL.Drawing
Imports System
Imports System.Collections.Generic

Private workBook As WorkBook = WorkBook.Load("insertImages.xlsx")
Private workSheet As WorkSheet = workBook.DefaultWorkSheet

' Retreive images
Private images As List(Of IronXL.Drawing.Images.IImage) = workSheet.Images

' Select each image
For Each image As IronXL.Drawing.Images.IImage In images
	' Save the image
	Dim anyBitmap As AnyBitmap = image.ToAnyBitmap()
	anyBitmap.SaveAs($"{image.Id}.png")

	' Resize the image
	image.Resize(1,3)

	' Retrieve image position
	Dim position As Position = image.Position
	Console.WriteLine("top row index: " & position.TopRowIndex)
	Console.WriteLine("bottom row index: " & position.BottomRowIndex)

	' Retrieve byte data
	Dim imageByte() As Byte = image.Data
Next image

workBook.SaveAs("resizeImage.xlsx")
$vbLabelText   $csharpLabel
Extracted Images
Image Size

Remove Image Example

Following the extract images example, you can easily remove any inserted image using its corresponding index number. Simply pass the image's ID number to the RemoveImage method to remove it from the worksheet.

:path=/static-assets/excel/content-code-examples/how-to/add-remove-extract-worksheet-images-remove.cs
using IronXL;

WorkBook workBook = WorkBook.Load("insertImages.xlsx");
WorkSheet workSheet = workBook.DefaultWorkSheet;

// Remove image
workSheet.RemoveImage(3);

workBook.SaveAs("removeImage.xlsx");
Imports IronXL

Private workBook As WorkBook = WorkBook.Load("insertImages.xlsx")
Private workSheet As WorkSheet = workBook.DefaultWorkSheet

' Remove image
workSheet.RemoveImage(3)

workBook.SaveAs("removeImage.xlsx")
$vbLabelText   $csharpLabel

Frequently Asked Questions

How can I add images to an Excel worksheet?

To insert an image into a spreadsheet using IronXL, use the `InsertImage` method. This method supports various image formats like JPG, BMP, PNG, GIF, and TIFF. You need to specify the top-left and bottom-right corners of the image to set its dimensions.

What image formats are supported by the InsertImage method?

The InsertImage method in IronXL supports multiple image formats including JPG/JPEG, BMP, PNG, GIF, and TIFF.

How do I extract images from an Excel worksheet?

To extract images using IronXL, access the `Images` property of the worksheet. This provides a list of all images, allowing you to export, resize, retrieve positions, and obtain the byte data of each image.

Can I remove images from an Excel worksheet?

Yes, you can remove images using IronXL by passing the image's ID number to the `RemoveImage` method. This will remove the specified image from the worksheet.

What is required to start using a library for image manipulation in Excel?

To begin using IronXL for manipulating images in Excel, you need to download the IronXL C# library from NuGet and either load an existing Excel file or create a new one.

How are image IDs generated?

Image IDs in IronXL follow an odd-numbered pattern, incrementing in the sequence of 1, 3, 5, 7, and so on.

Is it possible to export images extracted from an Excel worksheet?

Yes, once images are extracted using IronXL's `Images` property, they can be exported to formats such as PNG using the `Export` method.
