How to Detect Page Rotation

by Chaknith Bin

Determining page rotation involves identifying the degree of rotation applied to a page within a document. This process specifically determine if the page has been rotated clockwise or counterclockwise by angles of 0, 90, 180, and 270 degrees. This information is crucial for rendering or processing the document accurately, ensuring that pages are displayed or printed in their correct orientations.

IronOCR takes page rotation detection to the next level. Once rotation has been detected, the returned value can be used in combination with the Rotate method to adjust the image to the correct orientation.


C# NuGet Library for OCR

Install with NuGet

Install-Package IronOcr
or
C# OCR DLL

Download DLL

Download DLL

Manually install into your project

Detect Page Rotation Example

After loading the document, you can utilize the DetectPageOrientation method to identify the rotation of each page. This method supports degrees of 0, 90, 180, and 270. For skewed images, the Deskew image correction method can be used. Subsequently, rotate the image back to its original orientation using the degree returned from the function. Let's proceed with a sample PDF.

Please note
This function performs well when the document is text-dense.

:path=/static-assets/ocr/content-code-examples/how-to/detect-page-rotation-detect-page-rotation.cs
using IronOcr;
using System;

using var input = new OcrInput();

// Load PDF document
input.LoadPdf("Clockwise90.pdf");

// Detect page rotation
var results = input.DetectPageOrientation();

// Ouput result
foreach(var result in results)
{
    Console.WriteLine(result.PageNumber);
    Console.WriteLine(result.HighConfidence);
    Console.WriteLine(result.RotationAngle);
}
Imports IronOcr
Imports System

Private input = New OcrInput()

' Load PDF document
input.LoadPdf("Clockwise90.pdf")

' Detect page rotation
Dim results = input.DetectPageOrientation()

' Ouput result
For Each result In results
	Console.WriteLine(result.PageNumber)
	Console.WriteLine(result.HighConfidence)
	Console.WriteLine(result.RotationAngle)
Next result
VB   C#

Understanding the Result

  • PageNumber: Indicates the zero-based index of the page.
  • RotationAngle: Provides the corrective rotation angle in degrees. This angle can be applied to the Rotate method to return the image to right-side-up rotation. For example, if the image is rotated 90 degrees clockwise, the angle returned will be 270, which can then be passed to the Rotate method as input.Rotate(RotationAngle).
  • HighConfidence: Indicates the level of confidence in the orientation result.
