How to Generate Code 128 barcode in C#

Published March 6, 2024
Share:

Barcodes are crucial in modern business operations, from inventory management to product labeling and shipping.Code 128 stands out as a versatile and widely used option among the various barcode code sets. In this article, we’ll explore how to build a Code 128 barcode generator in C# using the IronBarcode library.

How to Generate Code 128 barcode in C#

  1. Install the IronBarcode library
  2. Generate a barcode using Code 128 Encoding
  3. Resize the barcode
  4. Style the barcode by changing the background and barcode color
  5. Read the created barcode

Introduction to Code 128 Barcodes

Code 128 code set is a high-density, variable-length linear barcode that can encode both alphanumeric data and special characters. It’s self-checking, which includes a checksum digit to ensure data accuracy. The Code 128 encoding scheme supports three control characters:

  1. Character Set A: Includes uppercase letters, digits, and special characters.
  2. Character Set B: Includes uppercase letters, lowercase letters, digits, and additional special characters.
  3. Character Set C: Encodes pairs of digits (00 to 99).

Why IronBarcode?

IronBarcode is a robust .NET library facilitating barcode generation, decoding, and customization. With support for various Barcode Encoding like Code 128, Code 39, Code 93, Code EAN 13, EAN 8, QR codes, and others. It offers an intuitive API for content, size, and appearance adjustments. Its decoding capabilities, automatic checksum calculation, and image export make it a valuable tool for developers in inventory management and beyond. The library's customization options for properties, margins, fonts, and colors enhance its versatility in barcode-related tasks.

Creating Code 128 Barcode Generator C#

Now, we will write code to generate code 128 barcode image in C#. The first step is to install the IronBarcode library in our project. The project can be of any type such as Windows Forms, web forms, MAUI, Xamarin, ASP.NET MVC, Razor, or Balzor projects.

Installing the IronBarcode library

To install the IronBarcode NuGet package using the Package Manager Console in Visual Studio, you can follow these steps:

  1. Open Visual Studio.
  2. In the top menu, go to "View" > "Other Windows" > "Package Manager Console" to open the Package Manager Console.
  3. In the Package Manager Console, you can use the Install-Package command to install the IronBarcode package. Type the following command and press Enter:

    Install-Package BarCode
  4. This command will download and install the latest version of the IronBarcode NuGet package and its dependencies into your project.

Add the following namespace to use the barcode library in your project.

using IronBarCode;
using IronBarCode;
Imports IronBarCode
VB   C#

Generate Code 128 Barcode Image

The following code will generate code 128 barcode.

var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
myBarcode.SaveAsJpeg("myBarcode.Jpeg");
var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
myBarcode.SaveAsJpeg("myBarcode.Jpeg");
Dim myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128)
myBarcode.SaveAsJpeg("myBarcode.Jpeg")
VB   C#

This code creates a barcode from the input string and saves it as a JPEG image file named “myBarcode.Jpeg.” The specific encoding used is Code 128, which can represent alphanumeric characters.

Explanation

The first line of code creates a new variable named myBarcode. It uses the BarcodeWriter.CreateBarcode method to generate a barcode based on the input string "12345ABC12345".

The second argument, 'BarcodeWriterEncoding.Code128', specifies the encoding type for the barcode. In this case, it’s using the Code 128 encoding, which is commonly used for alphanumeric data. The resulting barcode is stored in the myBarcode variable.

The second line saves the generated barcode as a JPEG image file. The filename for the saved image is "myBarcode.Jpeg". The format of the saved image is JPEG (Joint Photographic Experts Group).

Output

The generated barcode is as:

How to Generate Code 128 barcode in C#: Figure 1 - Outputted barcode from the previous code

This code now can be read using a barcode reading device.

Now, Let's resize our barcode.

Resize Barcode

The following code will resize our barcode as per the given dimension.

static void Main(string [] args)
 {
     var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
     myBarcode.ResizeTo(800,300); // width & height in pixels (px)
     myBarcode.SaveAsJpeg("myBarcode.Jpeg");
 }
static void Main(string [] args)
 {
     var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
     myBarcode.ResizeTo(800,300); // width & height in pixels (px)
     myBarcode.SaveAsJpeg("myBarcode.Jpeg");
 }
Shared Sub Main(ByVal args() As String)
	 Dim myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128)
	 myBarcode.ResizeTo(800,300) ' width & height in pixels (px)
	 myBarcode.SaveAsJpeg("myBarcode.Jpeg")
End Sub
VB   C#

The code for creating and saving barcodes remains the same. Just add the additional line to resize the barcode.

The ResizeTo() method resizes the barcode image stored in the myBarcode variable. The method ResizeTo is called on the myBarcode object. The two arguments passed to ResizeTo are width and height. In this case, the width is set to 800 pixels and the height is set to 300 pixels.

In this way, we can set the minimum width and bar module height. The resulting barcode image will have these dimensions after resizing as shown below.

Barcode Image

How to Generate Code 128 barcode in C#: Figure 2 - Resized barcode from the previous code

Now, Let's style our barcode.

Style Code 128 barcode

Now, Let's style our barcode by changing the background color and barcode color.

static void Main(string [] args)
 {
     var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
     myBarcode.ResizeTo(800,300);
     myBarcode.ChangeBackgroundColor(IronSoftware.Drawing.Color.Cornsilk);
     myBarcode.ChangeBarCodeColor(IronSoftware.Drawing.Color.Brown);
     myBarcode.SaveAsJpeg("myBarcode.Jpeg");
 }
static void Main(string [] args)
 {
     var myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128);
     myBarcode.ResizeTo(800,300);
     myBarcode.ChangeBackgroundColor(IronSoftware.Drawing.Color.Cornsilk);
     myBarcode.ChangeBarCodeColor(IronSoftware.Drawing.Color.Brown);
     myBarcode.SaveAsJpeg("myBarcode.Jpeg");
 }
Shared Sub Main(ByVal args() As String)
	 Dim myBarcode = BarcodeWriter.CreateBarcode("12345ABC12345", BarcodeWriterEncoding.Code128)
	 myBarcode.ResizeTo(800,300)
	 myBarcode.ChangeBackgroundColor(IronSoftware.Drawing.Color.Cornsilk)
	 myBarcode.ChangeBarCodeColor(IronSoftware.Drawing.Color.Brown)
	 myBarcode.SaveAsJpeg("myBarcode.Jpeg")
End Sub
VB   C#

The code for generating and saving barcodes is the same. I have just added two additional lines for changing the background and barcode color. The explanation is as:

The method ChangeBackgroundColor is called on the myBarcode object. This method changes the background color of the barcode image. The argument passed to ChangeBackgroundColor is IronSoftware.Drawing.Color.Cornsilk, which specifies the desired background color. In this case, the background color is set to Cornsilk, which is a pale yellowish color.

The method ChangeBarCodeColor is called on the myBarcode object. This method changes the color of the barcode bars. The argument passed to ChangeBarCodeColor is IronSoftware.Drawing.Color.Brown, which specifies the desired barcode color. In this case, the barcode color is set to Brown.

Output

Out styled Barcode is as:

How to Generate Code 128 barcode in C#: Figure 3 - Outputted styled barcode from the previous code

Read Code 128 Barcode

We have learned to generate code 128 barcode. Let's write a code to read the barcode:

static void Main(string [] args)
{
    var resultFromBarcode = BarcodeReader.Read("myBarcode.Jpeg");
    foreach (var barcodeValue in resultFromBarcode)
    {
        Console.WriteLine(barcodeValue);
    }
}
static void Main(string [] args)
{
    var resultFromBarcode = BarcodeReader.Read("myBarcode.Jpeg");
    foreach (var barcodeValue in resultFromBarcode)
    {
        Console.WriteLine(barcodeValue);
    }
}
Shared Sub Main(ByVal args() As String)
	Dim resultFromBarcode = BarcodeReader.Read("myBarcode.Jpeg")
	For Each barcodeValue In resultFromBarcode
		Console.WriteLine(barcodeValue)
	Next barcodeValue
End Sub
VB   C#

The above code reads barcodes from the “myBarcode.Jpeg” image file and prints their values to the console. The BarcodeReader class is responsible for decoding the barcode data from the image. The explanation of the code is as:

Explanation of Code

The first line creates a variable named resultFromBarcode. It calls the 'BarcodeReader.Read' method to read barcodes from the image file named “myBarcode.Jpeg”. The result of this operation is stored in the 'resultFromBarcode' variable.

The second line starts a loop that iterates through each barcode value in the 'resultFromBarcode' collection. The foreach loop allows us to process each barcode value one by one. Inside the loop, this line prints each barcode value to the console. The 'barcodeValue' represents the content of a barcode that was read from the image.

The barcode value will be printed on the Console as shown below.

Output

How to Generate Code 128 barcode in C#: Figure 4 - Console output from the read barcode

Conclusion

In conclusion, this article has demonstrated how to create a Code 128 barcode generator in C# using the IronBarcode library. By leveraging the capabilities of IronBarcode, developers can easily generate, customize, and style Code 128 barcodes for various applications, including inventory management, product labeling, and shipping. By following this tutorial, developers can integrate robust barcode functionality into their C# projects, enhancing efficiency in handling tasks related to barcode generation and decoding. IronBarcode's versatility and intuitive API make it a valuable tool for developers working on applications that involve barcode implementation.

In the process of generating Code 128 barcodes with the IronBarcode library, developers have the flexibility to customize code set selection characters, ensuring optimal encoding of data with varying ASCII values. The rendering code seamlessly adapts to preferred image formats, offering developers the choice to save barcodes in JPEG or other formats. Additionally, the inclusion of a stop character ensures the accurate termination of encoded information within the generated barcodes.

IronBarcode offers a free trial to unlock the full potential of the library for their development needs. This approach enables developers to assess the capabilities of IronBarcode before committing to the commercial license.
