使用 IRONQR 如何在 C# 中创建 QR 代码生成器应用 Jordi Bardia 已更新:七月 28, 2025 下载 IronQR NuGet 下载 免费试用 法学硕士副本 法学硕士副本 将页面复制为 Markdown 格式,用于 LLMs 在 ChatGPT 中打开 向 ChatGPT 咨询此页面 在双子座打开 向 Gemini 询问此页面 在双子座打开 向 Gemini 询问此页面 打开困惑 向 Perplexity 询问有关此页面的信息 分享 在 Facebook 上分享 分享到 X(Twitter) 在 LinkedIn 上分享 复制链接 电子邮件文章 欢迎使用我们的指南,了解如何使用C# 创建QR码! QR码和.NET条形码DLL已成为快速高效分享信息的流行方式。 无论您是在开发应用程序,管理网站,还是只是寻找一种整洁的方式分享链接,这些代码都能非常有用。 在本指南中,我们将演示如何使用IronQR高效生成QR码,确保您能生成满足您需求的QR码。 这个库使任何使用C#的人都可以轻松创建QR码,而无需深入复杂的逻辑。 我们将引导您完成每一步,确保您拥有开始所需的一切。 无论您是想在应用程序中添加QR码生成器功能还是只想了解它是如何完成的,您都来对地方了。 让我们开始吧。 如何在C#中创建QR码生成器 在Visual Studio中创建Windows Forms应用程序 使用NuGet安装QR库 设计表单前端元素 编写QR生成逻辑 运行应用程序并开始创建QR码 IronQR:C# QR库 IronQR是一个C# QR码库,用于将QR码功能集成到.NET应用程序中。 IronQR支持多种.NET版本和项目类型,包括C#、VB.NET、F#、.NET Core、.NET Standard、.NET Framework等,确保与各种开发环境兼容,如Windows、Linux、macOS、iOS和Android。 IronQR以其高级功能而著称,包括读取QR码和生成QR码、支持多种图像格式以及诸如重新调整大小、样式和在QR码上添加徽标等定制选项。 IronQR的一些关键功能 IronQR不仅限于基本的QR码生成,还提供多种功能,旨在适应各种与QR码相关的任务。 让我们来看看这些功能并检查它们的示例代码,您可以将它们集成到任何类型的.NET应用程序模板中,如控制台应用程序。 读取QR码 IronQR在解码QR码方面表现出色,为用户提供了一种访问嵌入在QR码中的信息的简单方法。 您可以快速准确地从QR码中提取数据,从简单的URL到复杂的嵌入信息皆可。 using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image file that contains the QR Code var inputImage = AnyBitmap.FromFile("QRCode.png"); // Prepare the image for QR code detection QrImageInput qrInput = new QrImageInput(inputImage); // Initialize the QR Code reader QrReader qrReader = new QrReader(); // Execute QR Code reading on the provided image IEnumerable<QrResult> qrResults = qrReader.Read(qrInput); // Print the value of each QR code found in the image foreach (var result in qrResults) { Console.WriteLine(result.Value); } using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image file that contains the QR Code var inputImage = AnyBitmap.FromFile("QRCode.png"); // Prepare the image for QR code detection QrImageInput qrInput = new QrImageInput(inputImage); // Initialize the QR Code reader QrReader qrReader = new QrReader(); // Execute QR Code reading on the provided image IEnumerable<QrResult> qrResults = qrReader.Read(qrInput); // Print the value of each QR code found in the image foreach (var result in qrResults) { Console.WriteLine(result.Value); } Imports IronQr Imports IronSoftware.Drawing Imports Color = IronSoftware.Drawing.Color ' Set the license key for IronQR IronQr.License.LicenseKey = "License-Key" ' Load the image file that contains the QR Code Dim inputImage = AnyBitmap.FromFile("QRCode.png") ' Prepare the image for QR code detection Dim qrInput As New QrImageInput(inputImage) ' Initialize the QR Code reader Dim qrReader As New QrReader() ' Execute QR Code reading on the provided image Dim qrResults As IEnumerable(Of QrResult) = qrReader.Read(qrInput) ' Print the value of each QR code found in the image For Each result In qrResults Console.WriteLine(result.Value) Next result $vbLabelText $csharpLabel 我们使用以下QR进行扫描: 并获得了以下输出: 该过程首先要结合必要的命名空间IronQr和Iron Software.Drawing,特别提到Iron Software.Drawing命名空间中的Color来处理图像操作。 在深入QR码读取过程之前,必须通过将许可证密钥分配给IronQr.License.LicenseKey来激活软件。 然后代码继续使用AnyBitmap.FromFile("QRCode.png")从文件加载QR码图像。 加载图像后,下一步就是准备它以进行QR码检测。 此准备通过创建一个QrImageInput对象完成,该对象充当图像的容器。 此功能的核心在于QrReader类,它被实例化并用于执行QR码读取操作。 读取器分析已准备的图像qrInput,寻找其中的任何QR码。 该操作的结果是一个QrResult对象的集合,每个对象代表图像中检测到的一个QR码。 要访问和利用QR码中编码的数据,代码使用foreach循环遍历结果集。每个QrResult对象包含诸如QR码的值等属性,可以访问并显示。 自定义QR读取模式选项 IronQR为您提供不同的方法从图像中读取QR码,使其适应各种需求。 其中一个选项是混合扫描模式,它平衡了速度和准确性,适用于QR码不清晰或部分隐藏的情况。 另一个选项是机器学习(ML)扫描模式,它使用智能技术读取受损或以通常方式不易读取的QR码。 此模式非常适用于在QR码难以检测的艰难情况下。 最后,还有基本扫描模式,这是扫描清晰且简单QR码的最快和最简单的方法。 它最适合当您需要快速结果且QR码易读。 using IronQr; using IronQr.Enum; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image file that contains the QR Code var inputImage = AnyBitmap.FromFile("QRCode.png"); // Using mixed scan mode QrImageInput mixedScanInput = new QrImageInput(inputImage, QrScanMode.OnlyDetectionModel); IEnumerable<QrResult> mixedScanResults = new QrReader().Read(mixedScanInput); // Using machine learning scan mode QrImageInput mlScanInput = new QrImageInput(inputImage, QrScanMode.OnlyDetectionModel); IEnumerable<QrResult> mlScanResults = new QrReader().Read(mlScanInput); // Using basic scan mode QrImageInput basicScanInput = new QrImageInput(inputImage, QrScanMode.OnlyBasicScan); IEnumerable<QrResult> basicScanResults = new QrReader().Read(basicScanInput); using IronQr; using IronQr.Enum; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image file that contains the QR Code var inputImage = AnyBitmap.FromFile("QRCode.png"); // Using mixed scan mode QrImageInput mixedScanInput = new QrImageInput(inputImage, QrScanMode.OnlyDetectionModel); IEnumerable<QrResult> mixedScanResults = new QrReader().Read(mixedScanInput); // Using machine learning scan mode QrImageInput mlScanInput = new QrImageInput(inputImage, QrScanMode.OnlyDetectionModel); IEnumerable<QrResult> mlScanResults = new QrReader().Read(mlScanInput); // Using basic scan mode QrImageInput basicScanInput = new QrImageInput(inputImage, QrScanMode.OnlyBasicScan); IEnumerable<QrResult> basicScanResults = new QrReader().Read(basicScanInput); Imports IronQr Imports IronQr.Enum Imports IronSoftware.Drawing Imports Color = IronSoftware.Drawing.Color ' Set the license key for IronQR IronQr.License.LicenseKey = "License-Key" ' Load the image file that contains the QR Code Dim inputImage = AnyBitmap.FromFile("QRCode.png") ' Using mixed scan mode Dim mixedScanInput As New QrImageInput(inputImage, QrScanMode.OnlyDetectionModel) Dim mixedScanResults As IEnumerable(Of QrResult) = (New QrReader()).Read(mixedScanInput) ' Using machine learning scan mode Dim mlScanInput As New QrImageInput(inputImage, QrScanMode.OnlyDetectionModel) Dim mlScanResults As IEnumerable(Of QrResult) = (New QrReader()).Read(mlScanInput) ' Using basic scan mode Dim basicScanInput As New QrImageInput(inputImage, QrScanMode.OnlyBasicScan) Dim basicScanResults As IEnumerable(Of QrResult) = (New QrReader()).Read(basicScanInput) $vbLabelText $csharpLabel 读取高级QR码 IronQR的高级QR码读取能力旨在提供对QR码扫描和解码的全面而细致的处理。 这一功能集不仅限于基本的QR码读取功能,还提供更深层次的互动和数据提取。 using IronQr; using IronQr.Enum; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image to scan var imageToScan = AnyBitmap.FromFile("QRCode.png"); // Prepare the image for QR code detection QrImageInput qrInput = new QrImageInput(imageToScan); // Initialize the QR Code reader QrReader qrScanner = new QrReader(); // Execute QR Code reading on the provided image IEnumerable<QrResult> scanResults = qrScanner.Read(qrInput); // Print the value, URL, and coordinates of each QR code found in the image foreach (QrResult qrResult in scanResults) { Console.WriteLine(qrResult.Value); Console.WriteLine(qrResult.Url); foreach (IronSoftware.Drawing.PointF coordinate in qrResult.Points) { Console.WriteLine($"{coordinate.X}, {coordinate.Y}"); } } using IronQr; using IronQr.Enum; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; // Set the license key for IronQR IronQr.License.LicenseKey = "License-Key"; // Load the image to scan var imageToScan = AnyBitmap.FromFile("QRCode.png"); // Prepare the image for QR code detection QrImageInput qrInput = new QrImageInput(imageToScan); // Initialize the QR Code reader QrReader qrScanner = new QrReader(); // Execute QR Code reading on the provided image IEnumerable<QrResult> scanResults = qrScanner.Read(qrInput); // Print the value, URL, and coordinates of each QR code found in the image foreach (QrResult qrResult in scanResults) { Console.WriteLine(qrResult.Value); Console.WriteLine(qrResult.Url); foreach (IronSoftware.Drawing.PointF coordinate in qrResult.Points) { Console.WriteLine($"{coordinate.X}, {coordinate.Y}"); } } Imports IronQr Imports IronQr.Enum Imports IronSoftware.Drawing Imports Color = IronSoftware.Drawing.Color ' Set the license key for IronQR IronQr.License.LicenseKey = "License-Key" ' Load the image to scan Dim imageToScan = AnyBitmap.FromFile("QRCode.png") ' Prepare the image for QR code detection Dim qrInput As New QrImageInput(imageToScan) ' Initialize the QR Code reader Dim qrScanner As New QrReader() ' Execute QR Code reading on the provided image Dim scanResults As IEnumerable(Of QrResult) = qrScanner.Read(qrInput) ' Print the value, URL, and coordinates of each QR code found in the image For Each qrResult As QrResult In scanResults Console.WriteLine(qrResult.Value) Console.WriteLine(qrResult.Url) For Each coordinate As IronSoftware.Drawing.PointF In qrResult.Points Console.WriteLine($"{coordinate.X}, {coordinate.Y}") Next coordinate Next qrResult $vbLabelText $csharpLabel 这是我们使用IronQR扫描QR码时获得的输出: 我们使用以下QR码: 每个QrResult对象提供对解码数据(Value)、任何嵌入的URL(Url)以及QR码在图像中的空间坐标(Points)的访问。 对于每个检测到的QR码,IronQR提供详细信息,包括QR码内包含的确切内容和任何URL。 此外,库还提供QR码在图像中角落的精确坐标(通过Points属性)。 要在C#应用程序中使用IronQR库创建一个QR码生成器,请仔细按照这些步骤进行。 本指南将带您从设置Windows窗体应用程序、安装IronQR库、编写生成QR码的代码到理解输出。 步骤1:在Visual Studio中创建Windows应用程序 首先,在您的计算机上启动Visual Studio。 点击"创建新项目"按钮。 选择Windows Forms App作为项目类型。 确保选择C#语言。 输入项目名称并选择保存位置。 然后在下一屏选择.NET Framework。 然后点击创建。 这将在Visual Studio中创建并打开一个Windows窗体应用程序。 步骤2:安装IronQR库 现在是时候在项目中安装IronQR库了。 您可以通过不同的方法安装IronQR库。 选择一个符合您偏好的方法: 使用NuGet包管理器安装 在Solution Explorer中右键单击您的项目并选择管理NuGet软件包。 在搜索框中键入IronQR并按Enter。 在列表中找到IronQR并点击旁边的安装。 使用NuGet包管理器控制台安装 前往工具 > NuGet包管理器 > 包管理器控制台。 键入Install-Package IronQR并按下Enter。 步骤3:设计前端 3.1 标题头 启动QR码生成器应用程序后,用户立即会看到一个引人注目的标题,名为"QR Generator IronQR",以一种粗体和权威的字体书写。 选择Agency FB字体是因为其线条干净现代,传达出高效和精准的感受。 以48点大小的字体,标题既突出又自信,捕捉用户的注意力,并牢固确立应用程序的身份。 3.2 输入部分 QR码的文本输入 在输入部分的核心是一个简单但基本的组件:文本输入框。 在这里,用户可以输入他们希望编码到QR码中的数据。 该框体宽敞,可容纳大量文本,并且被突出放置在顶部附近。 徽标选择 在文本输入之下,"选择徽标"区域允许用户进行额外的个性化定制。 用户可以上传一个将被嵌入在QR码中的徽标,增强品牌识别或使代码个性化。 相邻的图片框提供了选定徽标的预览,提供了即时的视觉反馈。 颜色配置 右侧的界面提供颜色选择的选项。 两个按钮,一个用于QR码的颜色,另一个用于背景颜色,允许用户自定义他们的QR码调色板。 这些按钮旁边的富文本框显示了当前选定的颜色。 输入部分合理布局,结合文本、徽标和颜色选项,用户可快速输入信息并留有创作余地。 它将功能与灵活性相结合,允许用户快速高效地输入所需的信息,同时也提供了创造性的空间。 3.3 样式参数 维度设置 在颜色定制工具旁,用户会找到"维度"输入。这个数值设置是关键,因为它决定了QR码的整体尺寸,确保其完美地适应预定的显示上下文,无论是名片、传单还是数字屏幕。 边距设置 边距设置 边距不仅仅是美学选择;它们是一个功能元素,可以影响扫描仪对QR码的可读性。 应用程序提供了一个数字上下控制,方便用户调整这个参数。 ### 3.4 输出预览 它充当动态显示,提供生成的QR码的实时预览。 这种即时的视觉反馈对用户验证他们的设计选择并确保QR码在保存前满足他们的期望至关重要。 ### 3.5 动作按钮 生成QR 此按钮被战略性地放置在表单内,是启动QR码创建过程的催化剂。 点击此按钮后,应用程序就会将用户定义的所有输入数据和样式参数并开始自定义QR码的生成。 #### 保存QR码 点击后,它会打开一个保存对话框,允许用户选择所需的文件格式和保存位置。 #### 重置表单 这是表单的重要方面,提供一种快速重新初始化应用程序而无需手动调整每个选项的方法。 这是表单的一个重要方面,提供了一种快速的方式来重新初始化应用程序,而无需手动调整每个选项。 第4步:编写后端逻辑 4.1 设置和初始化 首先,应用程序开始时要包含必要的命名空间:IronQr和Iron Software.Drawing。 定义自定义Color类以简化QR码生成中的颜色管理,覆盖默认的System.Drawing.Color以确保与IronQR的要求兼容。 QR_Generator类的构造函数在准备应用程序使用中起着至关重要的角色。 using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; Imports IronQr Imports IronSoftware.Drawing Imports Color = IronSoftware.Drawing.Color $vbLabelText $csharpLabel QR_Generator 类的构造函数在准备应用程序以供使用方面起着至关重要的作用。 * SetLicenseKey:此方法被调用以应用IronQR库的有效许可证密钥。 public QR_Generator() { InitializeComponent(); SetLicenseKey(); EnsureDirectoryExists(qrCodesDirectory); } public QR_Generator() { InitializeComponent(); SetLicenseKey(); EnsureDirectoryExists(qrCodesDirectory); } 'INSTANT VB WARNING: The following constructor is declared outside of its associated class: 'ORIGINAL LINE: public QR_Generator() Public Sub New() InitializeComponent() SetLicenseKey() EnsureDirectoryExists(qrCodesDirectory) End Sub $vbLabelText $csharpLabel SetLicenseKey:调用此方法以应用有效的 IronQR 库许可证密钥。 * EnsureDirectoryExists:鉴于需要保存生成的QR码,此方法确保存在一个专用目录。 EnsureDirectoryExists:鉴于需要保存生成的 QR 代码,此方法确保有一个专用目录可用。 它检查应用程序启动路径下是否存在"QR Codes"目录,如果不存在,则创建它。 为了确保IronQR无限制运行,必须应用有效的许可证密钥。 通过SetLicenseKey方法来实现,这是一个静态方法,用于用您购买或试用的许可证密钥配置库。 这是通过 SetLicenseKey 方法实现的, 该方法是一个静态方法,旨在使用您购买或试用的许可证密钥来配置库。 下面的代码片段演示了如何设置许可证密钥: private static void SetLicenseKey() { IronQr.License.LicenseKey = "YOUR_LICENSE_KEY"; } private static void SetLicenseKey() { IronQr.License.LicenseKey = "YOUR_LICENSE_KEY"; } Private Shared Sub SetLicenseKey() IronQr.License.LicenseKey = "YOUR_LICENSE_KEY" End Sub $vbLabelText $csharpLabel 该方法在QR_Generator类的构造函数中调用,确保许可证在应用程序启动和任何QR码生成开始之前就已应用。 ### 4.3 目录管理 该应用程序使用EnsureDirectoryExists方法来检查存储QR码的指定目录是否存在。 应用程序使用 EnsureDirectoryExists 方法检查用于存储 QR 代码的指定目录是否存在。 该方法接受一个string参数,即要检查或创建的目录路径。 此方法接受一个 string 参数,即要检查或创建的目录路径。 此方法利用System.IO命名空间与文件系统交互。 private static void EnsureDirectoryExists(string path) { if (!System.IO.Directory.Exists(path)) { System.IO.Directory.CreateDirectory(path); } } private static void EnsureDirectoryExists(string path) { if (!System.IO.Directory.Exists(path)) { System.IO.Directory.CreateDirectory(path); } } Private Shared Sub EnsureDirectoryExists(ByVal path As String) If Not System.IO.Directory.Exists(path) Then System.IO.Directory.CreateDirectory(path) End If End Sub $vbLabelText $csharpLabel 此方法利用System.IO命名空间与文件系统进行交互。 它首先使用Directory.Exists检查指定路径下的目录是否存在。 QR码目录的路径在QR_Generator类构造函数中定义为qrCodesDirectory,其结合了应用程序的启动路径和"QR Codes"文件夹名称: 4.4 颜色选择 string qrCodesDirectory = System.IO.Path.Combine(Application.StartupPath, "QR Codes"); string qrCodesDirectory = System.IO.Path.Combine(Application.StartupPath, "QR Codes"); Dim qrCodesDirectory As String = System.IO.Path.Combine(Application.StartupPath, "QR Codes") $vbLabelText $csharpLabel 该应用程序在用户界面中提供了两个按钮,每个按钮都绑有一个用于选择颜色的方法:btn_color_Click用于QR码颜色,btn_background_Click用于背景颜色。 该应用程序在用户界面上提供了两个按钮,每个按钮都与选择颜色的方法相关联:btn_color_Click 用于二维码颜色,btn_background_Click 用于背景颜色。 当使用颜色对话框选择颜色时,所选颜色将被转换为十六进制字符串格式。 当使用颜色对话框选择颜色时,所选择的颜色将转换为十六进制字符串格式。 这是必要的,因为IronQR库要求以十六进制格式指定颜色。 转换通过ColorToHex方法完成: private string ColorToHex(System.Drawing.Color color) { return $"#{color.R:X2}{color.G:X2}{color.B:X2}"; } private string ColorToHex(System.Drawing.Color color) { return $"#{color.R:X2}{color.G:X2}{color.B:X2}"; } Private Function ColorToHex(ByVal color As System.Drawing.Color) As String Return $"#{color.R:X2}{color.G:X2}{color.B:X2}" End Function $vbLabelText $csharpLabel UpdateColor方法获取所选择的颜色,并使用十六进制字符串将其转换为Iron Software.Drawing.Color格式,并根据选择更新二维码的前景或背景颜色。 它还更新UI以反映新的颜色选择: private void UpdateColor(ref Color targetColor, Control display, bool isBackground) { if (select_color.ShowDialog() == DialogResult.OK) { var hexColor = ColorToHex(select_color.Color); targetColor = new Color(hexColor); display.BackColor = select_color.Color; } } private void UpdateColor(ref Color targetColor, Control display, bool isBackground) { if (select_color.ShowDialog() == DialogResult.OK) { var hexColor = ColorToHex(select_color.Color); targetColor = new Color(hexColor); display.BackColor = select_color.Color; } } Private Sub UpdateColor(ByRef targetColor As Color, ByVal display As Control, ByVal isBackground As Boolean) If select_color.ShowDialog() = DialogResult.OK Then Dim hexColor = ColorToHex(select_color.Color) targetColor = New Color(hexColor) display.BackColor = select_color.Color End If End Sub $vbLabelText $csharpLabel 4.5 添加徽标 应用程序包含一个按钮(btn_logo_Click),点击时打开文件对话框,允许用户选择用于徽标的图像文件。 此功能对希望为其二维码品牌化的企业或个人至关重要。 以下是徽标选择和集成过程的处理方式: private void btn_logo_Click(object sender, EventArgs e) { if (select_logo.ShowDialog() == DialogResult.OK) { try { logoBmp = new AnyBitmap(select_logo.FileName); selected_logo.Image = Image.FromFile(select_logo.FileName); } catch (Exception ex) { ShowError("An error occurred while loading the logo", ex.Message); } } } private void btn_logo_Click(object sender, EventArgs e) { if (select_logo.ShowDialog() == DialogResult.OK) { try { logoBmp = new AnyBitmap(select_logo.FileName); selected_logo.Image = Image.FromFile(select_logo.FileName); } catch (Exception ex) { ShowError("An error occurred while loading the logo", ex.Message); } } } Private Sub btn_logo_Click(ByVal sender As Object, ByVal e As EventArgs) If select_logo.ShowDialog() = DialogResult.OK Then Try logoBmp = New AnyBitmap(select_logo.FileName) selected_logo.Image = Image.FromFile(select_logo.FileName) Catch ex As Exception ShowError("An error occurred while loading the logo", ex.Message) End Try End If End Sub $vbLabelText $csharpLabel 成功选择图像后,应用程序尝试加载它并显示预览。 AnyBitmap对象logoBmp随后设置为所选图像,二维码生成逻辑随后将使用此图像。 4.6 QR码生成 生成过程在用户单击"生成"按钮时开始,该按钮链接到btn_generate_Click方法。 此方法充当触发器,调用GenerateQRCode函数,实际生成逻辑在此处。 private void btn_generate_Click(object sender, EventArgs e) { GenerateQRCode(); } private void btn_generate_Click(object sender, EventArgs e) { GenerateQRCode(); } Private Sub btn_generate_Click(ByVal sender As Object, ByVal e As EventArgs) GenerateQRCode() End Sub $vbLabelText $csharpLabel 在GenerateQRCode方法内,应用程序根据指定的参数构建二维码,包括输入文本和样式选项。 该方法封装了二维码的创建,应用所选的颜色、尺寸、边距,并可选择添加徽标。 private void GenerateQRCode() { try { var options = new QrOptions(QrErrorCorrectionLevel.High); var myQr = QrWriter.Write(txt_QR.Text, options); var style = CreateStyleOptions(); var qrImage = myQr.Save(style); var fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png"; var fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName); qrImage.SaveAs(fullPath); pictureBox.Image = Image.FromFile(fullPath); } catch (Exception ex) { ShowError("An error occurred during QR code generation or saving", ex.Message); } } private void GenerateQRCode() { try { var options = new QrOptions(QrErrorCorrectionLevel.High); var myQr = QrWriter.Write(txt_QR.Text, options); var style = CreateStyleOptions(); var qrImage = myQr.Save(style); var fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png"; var fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName); qrImage.SaveAs(fullPath); pictureBox.Image = Image.FromFile(fullPath); } catch (Exception ex) { ShowError("An error occurred during QR code generation or saving", ex.Message); } } Private Sub GenerateQRCode() Try Dim options = New QrOptions(QrErrorCorrectionLevel.High) Dim myQr = QrWriter.Write(txt_QR.Text, options) Dim style = CreateStyleOptions() Dim qrImage = myQr.Save(style) Dim fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png" Dim fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName) qrImage.SaveAs(fullPath) pictureBox.Image = Image.FromFile(fullPath) Catch ex As Exception ShowError("An error occurred during QR code generation or saving", ex.Message) End Try End Sub $vbLabelText $csharpLabel QrOptions对象定义错误纠正级别,提高二维码抵御损坏或遮挡的能力。 CreateStyleOptions方法生成QrStyleOptions对象,其中包括用户的自定义设置,如颜色、尺寸和徽标。 这里是详细的方法: private QrStyleOptions CreateStyleOptions() { return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; } private QrStyleOptions CreateStyleOptions() { return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; } Private Function CreateStyleOptions() As QrStyleOptions 'INSTANT VB TODO TASK: Throw expressions are not converted by Instant VB: 'ORIGINAL LINE: return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; Return New QrStyleOptions With { .BackgroundColor = bgColor, .Color = color, .Dimensions = If(txt_dimension.Value > 0, Convert.ToInt32(txt_dimension.Value), throw New ArgumentException("Please select valid dimensions!")), .Margins = Convert.ToInt32(txt_margin.Value), .Logo = If(logoBmp IsNot Nothing, New QrLogo With { .Bitmap = logoBmp, .Width = 50, .Height = 50, .CornerRadius = 5 }, Nothing) } End Function $vbLabelText $csharpLabel 此方法创建一个 QrStyleOptions 对象,随后由二维码生成逻辑使用,以应用用户的偏好。 选项包括: BackgroundColor 和 Color:这些属性设置二维码的背景和前景颜色,允许个性化外观,可以与品牌或美学偏好相匹配。 Dimensions:此属性确定二维码的大小,提供二维码在不同上下文或介质中适配的灵活性。 Margins:此属性设置二维码周围的边距大小,确保其与周围元素隔离,这对可扩展性至关重要。 Logo:如果用户选择包含一个logo,则在此处配置其特定尺寸和角半径,以获得精致的外观。 4.7 保存二维码 保存功能通过"保存"按钮触发,该按钮链接到 btn_save_Click 方法。 此方法调用 SaveQRCode,实现保存逻辑。 该过程包括显示保存文件对话框,允许用户选择保存二维码的文件格式和位置。 private void btn_save_Click(object sender, EventArgs e) { SaveQRCode(); } private void SaveQRCode() { if (pictureBox.Image == null) { MessageBox.Show("There is no QR code to save.", "Error"); return; } saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg"; saveFileDialog.Title = "Save QR Code"; saveFileDialog.FileName = "QRCode"; if (saveFileDialog.ShowDialog() == DialogResult.OK) { try { pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)); MessageBox.Show("QR Code has been saved!", "Success"); } catch (Exception ex) { ShowError("An error occurred while saving the QR code", ex.Message); } } } private void btn_save_Click(object sender, EventArgs e) { SaveQRCode(); } private void SaveQRCode() { if (pictureBox.Image == null) { MessageBox.Show("There is no QR code to save.", "Error"); return; } saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg"; saveFileDialog.Title = "Save QR Code"; saveFileDialog.FileName = "QRCode"; if (saveFileDialog.ShowDialog() == DialogResult.OK) { try { pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)); MessageBox.Show("QR Code has been saved!", "Success"); } catch (Exception ex) { ShowError("An error occurred while saving the QR code", ex.Message); } } } Private Sub btn_save_Click(ByVal sender As Object, ByVal e As EventArgs) SaveQRCode() End Sub Private Sub SaveQRCode() If pictureBox.Image Is Nothing Then MessageBox.Show("There is no QR code to save.", "Error") Return End If saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg" saveFileDialog.Title = "Save QR Code" saveFileDialog.FileName = "QRCode" If saveFileDialog.ShowDialog() = DialogResult.OK Then Try pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)) MessageBox.Show("QR Code has been saved!", "Success") Catch ex As Exception ShowError("An error occurred while saving the QR code", ex.Message) End Try End If End Sub $vbLabelText $csharpLabel 此方法检查是否有生成的二维码可用。 如果有,它将向用户提供将文件保存为 PNG 或 JPEG 格式的选项。 DetermineImageFormat 函数确保图像根据用户选择的文件扩展名以正确的格式保存。 private System.Drawing.Imaging.ImageFormat DetermineImageFormat(string filePath) { return System.IO.Path.GetExtension(filePath).ToLower() == ".jpg" ? System.Drawing.Imaging.ImageFormat.Jpeg : System.Drawing.Imaging.ImageFormat.Png; } private System.Drawing.Imaging.ImageFormat DetermineImageFormat(string filePath) { return System.IO.Path.GetExtension(filePath).ToLower() == ".jpg" ? System.Drawing.Imaging.ImageFormat.Jpeg : System.Drawing.Imaging.ImageFormat.Png; } Private Function DetermineImageFormat(ByVal filePath As String) As System.Drawing.Imaging.ImageFormat Return If(System.IO.Path.GetExtension(filePath).ToLower() = ".jpg", System.Drawing.Imaging.ImageFormat.Jpeg, System.Drawing.Imaging.ImageFormat.Png) End Function $vbLabelText $csharpLabel 这种灵活性允许用户选择最适合其需求的格式,无论是优先考虑质量(PNG)还是文件大小(JPEG)。 4.8 重置应用程序 重置功能链接到"重置"按钮,该按钮调用 btn_reset_Click 方法。 该方法随后调用 ResetFields,该函数旨在清除所有用户输入并恢复所有设置的默认值,包括文本字段、颜色选择和所选徽标。 private void btn_reset_Click(object sender, EventArgs e) { ResetFields(); } private void ResetFields() { txt_QR.Text = string.Empty; txt_dimension.Value = 200; txt_margin.Value = 0; bgColor = Color.White; color = Color.Black; txt_selected_color.BackColor = bgColor; txt_selected_bgcolor.BackColor = color; logoBmp = null; selected_logo.Image = null; pictureBox.Image = null; } private void btn_reset_Click(object sender, EventArgs e) { ResetFields(); } private void ResetFields() { txt_QR.Text = string.Empty; txt_dimension.Value = 200; txt_margin.Value = 0; bgColor = Color.White; color = Color.Black; txt_selected_color.BackColor = bgColor; txt_selected_bgcolor.BackColor = color; logoBmp = null; selected_logo.Image = null; pictureBox.Image = null; } Private Sub btn_reset_Click(ByVal sender As Object, ByVal e As EventArgs) ResetFields() End Sub Private Sub ResetFields() txt_QR.Text = String.Empty txt_dimension.Value = 200 txt_margin.Value = 0 bgColor = Color.White color = Color.Black txt_selected_color.BackColor = bgColor txt_selected_bgcolor.BackColor = color logoBmp = Nothing selected_logo.Image = Nothing pictureBox.Image = Nothing End Sub $vbLabelText $csharpLabel 此方法重置二维码生成中涉及的每个组件。 例如,它清除二维码文本,将尺寸和边距设置为默认值,并删除任何选择的颜色或logo。 4.9 错误处理 该应用程序使用 ShowError 方法以用户友好的方式显示错误消息。 该方法在应用程序的不同部份中被利用,以确保当发生错误时,能立即通过一个清晰简洁的信息通知用户。 此方法利用System.IO命名空间与文件系统交互。 private static void ShowError(string title, string message) { MessageBox.Show($"{title}: {message}", "Error"); } private static void ShowError(string title, string message) { MessageBox.Show($"{title}: {message}", "Error"); } Private Shared Sub ShowError(ByVal title As String, ByVal message As String) MessageBox.Show($"{title}: {message}", "Error") End Sub $vbLabelText $csharpLabel 此方法在应用程序的不同部分中使用,以确保当发生错误时,用户会被及时以清晰简明的消息通知。 例如,如果在加载logo时或在生成二维码过程中发生错误,应用程序会调用 ShowError 来显示有关问题的详细信息。 4.10 完整代码示例 这是完整代码,帮助您更容易理解代码: using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; namespace IronQR_QR_Generator_WinForms { public partial class QR_Generator : Form { string qrCodesDirectory = System.IO.Path.Combine(Application.StartupPath, "QR Codes"); Color bgColor = Color.White; Color color = Color.Black; AnyBitmap? logoBmp = null; public QR_Generator() { InitializeComponent(); SetLicenseKey(); EnsureDirectoryExists(qrCodesDirectory); } private static void SetLicenseKey() { IronQr.License.LicenseKey = "License-Key"; } private static void EnsureDirectoryExists(string path) { if (!System.IO.Directory.Exists(path)) { System.IO.Directory.CreateDirectory(path); } } private void btn_color_Click(object sender, EventArgs e) { UpdateColor(ref color, txt_selected_color, false); } private void btn_background_Click(object sender, EventArgs e) { UpdateColor(ref bgColor, txt_selected_bgcolor, true); } private string ColorToHex(System.Drawing.Color color) { return $"#{color.R:X2}{color.G:X2}{color.B:X2}"; } private void UpdateColor(ref Color targetColor, Control display, bool isBackground) { if (select_color.ShowDialog() == DialogResult.OK) { var hexColor = ColorToHex(select_color.Color); targetColor = new Color(hexColor); display.BackColor = select_color.Color; } } private void btn_logo_Click(object sender, EventArgs e) { if (select_logo.ShowDialog() == DialogResult.OK) { try { logoBmp = new AnyBitmap(select_logo.FileName); selected_logo.Image = Image.FromFile(select_logo.FileName); } catch (Exception ex) { ShowError("An error occurred while loading the logo", ex.Message); } } } private void btn_generate_Click(object sender, EventArgs e) { GenerateQRCode(); } private void GenerateQRCode() { try { var options = new QrOptions(QrErrorCorrectionLevel.High); var myQr = QrWriter.Write(txt_QR.Text, options); var style = CreateStyleOptions(); var qrImage = myQr.Save(style); var fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png"; var fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName); qrImage.SaveAs(fullPath); pictureBox.Image = Image.FromFile(fullPath); } catch (Exception ex) { ShowError("An error occurred during QR code generation or saving", ex.Message); } } private QrStyleOptions CreateStyleOptions() { return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; } private void btn_save_Click(object sender, EventArgs e) { SaveQRCode(); } private void SaveQRCode() { if (pictureBox.Image == null) { MessageBox.Show("There is no QR code to save.", "Error"); return; } saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg"; saveFileDialog.Title = "Save QR Code"; saveFileDialog.FileName = "QRCode"; if (saveFileDialog.ShowDialog() == DialogResult.OK) { try { pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)); MessageBox.Show("QR Code has been saved!", "Success"); } catch (Exception ex) { ShowError("An error occurred while saving the QR code", ex.Message); } } } private System.Drawing.Imaging.ImageFormat DetermineImageFormat(string filePath) { return System.IO.Path.GetExtension(filePath).ToLower() == ".jpg" ? System.Drawing.Imaging.ImageFormat.Jpeg : System.Drawing.Imaging.ImageFormat.Png; } private void btn_reset_Click(object sender, EventArgs e) { ResetFields(); } private void ResetFields() { txt_QR.Text = string.Empty; txt_dimension.Value = 200; txt_margin.Value = 0; bgColor = Color.White; color = Color.Black; txt_selected_color.BackColor = bgColor; txt_selected_bgcolor.BackColor = color; logoBmp = null; selected_logo.Image = null; pictureBox.Image = null; } private static void ShowError(string title, string message) { MessageBox.Show($"{title}: {message}", "Error"); } } } using IronQr; using IronSoftware.Drawing; using Color = IronSoftware.Drawing.Color; namespace IronQR_QR_Generator_WinForms { public partial class QR_Generator : Form { string qrCodesDirectory = System.IO.Path.Combine(Application.StartupPath, "QR Codes"); Color bgColor = Color.White; Color color = Color.Black; AnyBitmap? logoBmp = null; public QR_Generator() { InitializeComponent(); SetLicenseKey(); EnsureDirectoryExists(qrCodesDirectory); } private static void SetLicenseKey() { IronQr.License.LicenseKey = "License-Key"; } private static void EnsureDirectoryExists(string path) { if (!System.IO.Directory.Exists(path)) { System.IO.Directory.CreateDirectory(path); } } private void btn_color_Click(object sender, EventArgs e) { UpdateColor(ref color, txt_selected_color, false); } private void btn_background_Click(object sender, EventArgs e) { UpdateColor(ref bgColor, txt_selected_bgcolor, true); } private string ColorToHex(System.Drawing.Color color) { return $"#{color.R:X2}{color.G:X2}{color.B:X2}"; } private void UpdateColor(ref Color targetColor, Control display, bool isBackground) { if (select_color.ShowDialog() == DialogResult.OK) { var hexColor = ColorToHex(select_color.Color); targetColor = new Color(hexColor); display.BackColor = select_color.Color; } } private void btn_logo_Click(object sender, EventArgs e) { if (select_logo.ShowDialog() == DialogResult.OK) { try { logoBmp = new AnyBitmap(select_logo.FileName); selected_logo.Image = Image.FromFile(select_logo.FileName); } catch (Exception ex) { ShowError("An error occurred while loading the logo", ex.Message); } } } private void btn_generate_Click(object sender, EventArgs e) { GenerateQRCode(); } private void GenerateQRCode() { try { var options = new QrOptions(QrErrorCorrectionLevel.High); var myQr = QrWriter.Write(txt_QR.Text, options); var style = CreateStyleOptions(); var qrImage = myQr.Save(style); var fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png"; var fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName); qrImage.SaveAs(fullPath); pictureBox.Image = Image.FromFile(fullPath); } catch (Exception ex) { ShowError("An error occurred during QR code generation or saving", ex.Message); } } private QrStyleOptions CreateStyleOptions() { return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; } private void btn_save_Click(object sender, EventArgs e) { SaveQRCode(); } private void SaveQRCode() { if (pictureBox.Image == null) { MessageBox.Show("There is no QR code to save.", "Error"); return; } saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg"; saveFileDialog.Title = "Save QR Code"; saveFileDialog.FileName = "QRCode"; if (saveFileDialog.ShowDialog() == DialogResult.OK) { try { pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)); MessageBox.Show("QR Code has been saved!", "Success"); } catch (Exception ex) { ShowError("An error occurred while saving the QR code", ex.Message); } } } private System.Drawing.Imaging.ImageFormat DetermineImageFormat(string filePath) { return System.IO.Path.GetExtension(filePath).ToLower() == ".jpg" ? System.Drawing.Imaging.ImageFormat.Jpeg : System.Drawing.Imaging.ImageFormat.Png; } private void btn_reset_Click(object sender, EventArgs e) { ResetFields(); } private void ResetFields() { txt_QR.Text = string.Empty; txt_dimension.Value = 200; txt_margin.Value = 0; bgColor = Color.White; color = Color.Black; txt_selected_color.BackColor = bgColor; txt_selected_bgcolor.BackColor = color; logoBmp = null; selected_logo.Image = null; pictureBox.Image = null; } private static void ShowError(string title, string message) { MessageBox.Show($"{title}: {message}", "Error"); } } } Imports IronQr Imports IronSoftware.Drawing Imports Color = IronSoftware.Drawing.Color Namespace IronQR_QR_Generator_WinForms Partial Public Class QR_Generator Inherits Form Private qrCodesDirectory As String = System.IO.Path.Combine(Application.StartupPath, "QR Codes") Private bgColor As Color = Color.White Private color As Color = Color.Black Private logoBmp? As AnyBitmap = Nothing Public Sub New() InitializeComponent() SetLicenseKey() EnsureDirectoryExists(qrCodesDirectory) End Sub Private Shared Sub SetLicenseKey() IronQr.License.LicenseKey = "License-Key" End Sub Private Shared Sub EnsureDirectoryExists(ByVal path As String) If Not System.IO.Directory.Exists(path) Then System.IO.Directory.CreateDirectory(path) End If End Sub Private Sub btn_color_Click(ByVal sender As Object, ByVal e As EventArgs) UpdateColor(color, txt_selected_color, False) End Sub Private Sub btn_background_Click(ByVal sender As Object, ByVal e As EventArgs) UpdateColor(bgColor, txt_selected_bgcolor, True) End Sub Private Function ColorToHex(ByVal color As System.Drawing.Color) As String Return $"#{color.R:X2}{color.G:X2}{color.B:X2}" End Function Private Sub UpdateColor(ByRef targetColor As Color, ByVal display As Control, ByVal isBackground As Boolean) If select_color.ShowDialog() = System.Windows.Forms.DialogResult.OK Then Dim hexColor = ColorToHex(select_color.Color) targetColor = New Color(hexColor) display.BackColor = select_color.Color End If End Sub Private Sub btn_logo_Click(ByVal sender As Object, ByVal e As EventArgs) If select_logo.ShowDialog() = System.Windows.Forms.DialogResult.OK Then Try logoBmp = New AnyBitmap(select_logo.FileName) selected_logo.Image = Image.FromFile(select_logo.FileName) Catch ex As Exception ShowError("An error occurred while loading the logo", ex.Message) End Try End If End Sub Private Sub btn_generate_Click(ByVal sender As Object, ByVal e As EventArgs) GenerateQRCode() End Sub Private Sub GenerateQRCode() Try Dim options = New QrOptions(QrErrorCorrectionLevel.High) Dim myQr = QrWriter.Write(txt_QR.Text, options) Dim style = CreateStyleOptions() Dim qrImage = myQr.Save(style) Dim fileName = $"{DateTime.Now:yyyyMMddHHmmssfff}_QR.png" Dim fullPath = System.IO.Path.Combine(qrCodesDirectory, fileName) qrImage.SaveAs(fullPath) pictureBox.Image = Image.FromFile(fullPath) Catch ex As Exception ShowError("An error occurred during QR code generation or saving", ex.Message) End Try End Sub Private Function CreateStyleOptions() As QrStyleOptions 'INSTANT VB TODO TASK: Throw expressions are not converted by Instant VB: 'ORIGINAL LINE: return new QrStyleOptions { BackgroundColor = bgColor, Color = color, Dimensions = txt_dimension.Value > 0 ? Convert.ToInt32(txt_dimension.Value) : throw new ArgumentException("Please select valid dimensions!"), Margins = Convert.ToInt32(txt_margin.Value), Logo = logoBmp != null ? new QrLogo { Bitmap = logoBmp, Width = 50, Height = 50, CornerRadius = 5 } : null }; Return New QrStyleOptions With { .BackgroundColor = bgColor, .Color = color, .Dimensions = If(txt_dimension.Value > 0, Convert.ToInt32(txt_dimension.Value), throw New ArgumentException("Please select valid dimensions!")), .Margins = Convert.ToInt32(txt_margin.Value), .Logo = If(logoBmp IsNot Nothing, New QrLogo With { .Bitmap = logoBmp, .Width = 50, .Height = 50, .CornerRadius = 5 }, Nothing) } End Function Private Sub btn_save_Click(ByVal sender As Object, ByVal e As EventArgs) SaveQRCode() End Sub Private Sub SaveQRCode() If pictureBox.Image Is Nothing Then MessageBox.Show("There is no QR code to save.", "Error") Return End If saveFileDialog.Filter = "PNG Files|*.png|JPEG Files|*.jpg" saveFileDialog.Title = "Save QR Code" saveFileDialog.FileName = "QRCode" If saveFileDialog.ShowDialog() = System.Windows.Forms.DialogResult.OK Then Try pictureBox.Image.Save(saveFileDialog.FileName, DetermineImageFormat(saveFileDialog.FileName)) MessageBox.Show("QR Code has been saved!", "Success") Catch ex As Exception ShowError("An error occurred while saving the QR code", ex.Message) End Try End If End Sub Private Function DetermineImageFormat(ByVal filePath As String) As System.Drawing.Imaging.ImageFormat Return If(System.IO.Path.GetExtension(filePath).ToLower() = ".jpg", System.Drawing.Imaging.ImageFormat.Jpeg, System.Drawing.Imaging.ImageFormat.Png) End Function Private Sub btn_reset_Click(ByVal sender As Object, ByVal e As EventArgs) ResetFields() End Sub Private Sub ResetFields() txt_QR.Text = String.Empty txt_dimension.Value = 200 txt_margin.Value = 0 bgColor = Color.White color = Color.Black txt_selected_color.BackColor = bgColor txt_selected_bgcolor.BackColor = color logoBmp = Nothing selected_logo.Image = Nothing pictureBox.Image = Nothing End Sub Private Shared Sub ShowError(ByVal title As String, ByVal message As String) MessageBox.Show($"{title}: {message}", "Error") End Sub End Class End Namespace $vbLabelText $csharpLabel 步骤 5:运行应用程序 布局整齐地分为输入、样式、输出和操作部分。 该过程的第一步涉及在"输入二维码文本"字段中输入数据。 接下来,为了个性化QR码,通过点击"选择徽标"按钮选择一个徽标。 选择后,徽标被明显地放置在按钮旁边的预览框中,确认其已经合并到QR码设计中。 点击相应的按钮后,选择的颜色在每个按钮旁边的颜色显示框中反映,立即提供了对我们选择的视觉确认。 应用程序处理我们的输入并在输出图片框中显示新创建的QR码。 应用程序处理我们的输入并在输出图片框中显示新创建的二维码。 要保存生成的二维码,我们只需点击"保存二维码"按钮。 这项操作打开一个保存对话框,允许我们选择QR代码图像的目标和文件格式。 !如何创建一个C#的QR代码生成器应用程序:图26 - 保存对话框 一旦保存,成功消息确认QR代码已成功存储。 如果需要重新开始或创建新的二维码,点击"重置表单"按钮会将表单恢复到原始状态,清除所有字段和选择,为下一次二维码生成做好准备。 这是由IronQR生成的已保存二维码: 结论 总之,本指南引导您完成在C#应用程序中使用IronQR库生成二维码的过程。 通过分解从在Visual Studio中设置项目、集成IronQR库、设计用户友好的界面到编写后端逻辑的步骤,我们展示了为您的应用程序添加二维码功能的便捷性。 对于那些有兴趣进一步探索IronQR功能的人,值得注意的是,IronQR提供了一个免费试用供您入门。 如果您决定将IronQR集成到您的项目中,许可证的起价为$799,为专业级QR代码生成提供了具有成本效益的解决方案。 常见问题解答 如何在C#中创建二维码生成器应用程序? 要在C#中创建二维码生成器应用程序,首先在Visual Studio中设置Windows窗体应用程序。通过NuGet安装IronQR库,设计带有文本、徽标和颜色输入字段的界面,然后使用IronQR的方法实现二维码生成逻辑。 C#中的二维码有哪些定制选项? IronQR提供了二维码的定制选项,例如更改颜色、尺寸和边距。你也可以通过在QrStyleOptions对象中调整设置来向二维码中添加徽标。 如何在C#项目中安装二维码库? 在Visual Studio中使用NuGet包管理器安装IronQR库到你的C#项目中。搜索IronQR并点击“安装”按钮将其添加到你的项目中。 我可以使用哪些格式在C#中保存生成的二维码? 使用IronQR,可以生成并保存为包括PNG和JPEG在内的各种格式的二维码,以便在质量和文件大小方面灵活选择。 我可以使用C#库读取二维码吗? 是的,IronQR包括读取二维码的功能,使得可以有效地解码和提取QR图像中的数据。 使用C#二维码库有什么好处? 像IronQR这样的C#二维码库简化了生成和读取二维码的过程,它提供多格式支持、定制选项以及与各种.NET版本的兼容性。 如何在C#中处理二维码生成时的错误? 可以通过在C#中使用try-catch块将错误处理集成到二维码生成应用程序中。这样可以确保在生成二维码过程中出现的任何问题得到顺利处理,并提供用户友好的反馈。 在C#应用程序中使用二维码库需要许可证吗? 是的,若要不受限制地使用IronQR,您需要一个有效的许可证密钥。试用版可用于初步测试,购买专业许可证可以获得完整访问权限。 如何在C#中将徽标集成到二维码中? 使用IronQR,可以通过在QrStyleOptions对象中设置徽标图像来将徽标集成到二维码中。这允许您使用品牌元素个性化二维码。 运行C#中的二维码生成应用程序的步骤是什么? 在C#中设置并自定义二维码生成应用程序后,只需在Visual Studio中运行该应用程序,生成二维码,并使用提供的选项保存为您所需的格式。 Jordi Bardia 立即与工程团队聊天 软件工程师 Jordi 最擅长 Python、C# 和 C++,当他不在 Iron Software 利用这些技能时,他就在游戏编程。分享产品测试、产品开发和研究的责任,Jordi 在持续的产品改进中增加了巨大的价值。多样的经验使他面临挑战并保持投入,他表示这是在 Iron Software 工作的最喜欢的方面之一。Jordi 在佛罗里达州迈阿密长大,并在佛罗里达大学学习计算机科学和统计学。 相关文章 已更新九月 18, 2025 如何在 C# 中从图像读取 QR 在本指南中,我们将引导您如何使用专为 .NET 构建的高性能 QR 代码库 IronQR,只需几行 C# 代码即可从图像读取 QR 代码。 阅读更多 已更新八月 20, 2025 如何使用 .NET MAUI 进行 QR 代码扫描 本文将引导您使用 IronQR 创建 .NET MAUI 条形码扫描器和 QR 代码阅读器。 阅读更多 已更新七月 28, 2025 如何在 Visual Studio 中生成 QR 代码 或者,您可以通过 Visual Studio 的 NuGet 软件包管理器界面搜索“IronQR”并选择最新稳定版本。 阅读更多 如何在 C# 中读取 QR 代码如何使用 QRCoder 比较 IronQR ...
